Product Details:
Payment & Shipping Terms:
|
Material: | 195 | Wire Dia.: | 1.5-3.0mm |
---|---|---|---|
Opening: | 1"x1",2"x2",2"x3",2"x4" | Width: | 0.5-2.8m |
Treating: | Electro Galvanzied Wire,hot-dipped Galvanized Wire,or Hot Dipped After Welding | Hole Shape: | Square Or Long Hole |
Type: | Welded | Application: | Construction Wire Mesh |
High Light: | BWG15 50 Ft Welded Wire Fencing,BWG15 1 X 2 Wire Mesh Fencing,Construction 50 Ft Welded Wire Fencing |
Specification List of Welded Wire Mesh |
||
Opening |
Wire Diameter<BWG> |
|
In inch |
In metric unit(mm) |
|
1/4" x 1/4" |
6.4mm x 6.4mm |
22,23,24 |
3/8" x 3/8" |
10.6mm x 10.6mm |
9,20,21,22 |
1/2" x 1/2" |
12.7mm x 12.7mm |
16,17,18,19,20,21,22,23 |
5/8" x 5/8" |
16mm x 16mm |
18,19,20,21, |
3/4" x 3/4" |
19.1mm x 19.1mm |
16,17,18,19,20,21 |
1" x 1/2" |
25.4mm x 12.7mm |
16,17,18,19,20,21 |
1-1/2" x 1-1/2" |
38mm x 38mm |
14,15,16,17,18,19 |
1" x 2" |
25.4mm x 50.8mm |
14,15,16 |
2" x 2" |
50.8mm x 50.8mm |
12,13,14,15,16 |
